INTERTECHNIK | Air core rolls

LU44/033/100 | 0,33 mH | 0,30 Ω | 3% | 18 AWG | Air Coil

SKU: LU44/033/100
0.33 mH 1 mm
* Role: Experienced UK e-commerce copywriter. * Product: LU44/033/100 | 0,33 mH | 0,30 Ω | 3% | 18 AWG | Air Coil (Intertechnik). * Data: Induktivitás (Inductance): 0.33mH, Huzalátmérő (Wire diameter): 1mm, Külső átmérő (Outer diameter): 44mm, Süllyesztés átmérője (Recess diameter): 25.5mm, Központi furat (Central hole): 5.3mm, Magátmérő (Core diameter): 28mm, Teljes magasság (Total height): 30mm, Tekercselési szélesség (Winding width): 23mm, Ellenállás (Resistance): 0.3Ω, Tűrés (Tolerance): ±3%. * Rules: * Length: 2-3 sentences, max 300 characters. * First sentence: Start with strongest benefit/use case (NOT product name). * Keyword: Include "LU44/033/100 | 0,33 mH | 0,30 Ω | 3% | 18 AWG | Air Coil" naturally once. * No hype words: No "premium", "perfect", "fantastic", "best", etc. * Last sentence: Must include one concrete technical detail. * Format: Plain prose, no bullets. * Tone: Professional, concise, informative. * Language: British English (UK spelling). * Output: Only the finished text. * Product is an air core inductor (Air Coil). * Common uses: Crossovers, filters, audio electronics. * Key specs: 0.33mH, 0.30Ω, 3% tolerance, 18 AWG. * *Sentence 1 (Benefit/Use Case):* Ideal for high-precision audio crossover and filter circuits. * *Sentence 2 (Keyword):* This LU44/033/100 | 0,33 mH | 0,30 Ω | 3% | 18 AWG | Air Coil from Intertechnik ensures stable performance in demanding electronic applications. * *Sentence 3 (Technical Detail):* It features a total height of 30mm. * *Draft 1:* Ideal for high-precision audio crossover and filter circuits. This LU44/033/100 | 0,33 mH | 0,30 Ω | 3% | 18 AWG | Air Coil provides stable inductance for demanding electronic applications. The component has a total height of 30mm. * *Check constraints:* * 2-3 sentences? Yes (3). * Max 300 chars? 218 characters. * First sentence start with benefit? Yes ("Ideal for..."). * Keyword included? Yes. * No hype words? "Ideal" is borderline, but usually acceptable as a functional descriptor. Let's check others: "stable" is okay. No "premium", etc. * Last sentence technical detail? Yes (30mm height). * No bullets? Yes. * UK English? Yes. * *Refining for tone:* "Ideal" might be seen as a hype word by some strict standards, though it's more descriptive here. Let's try "Designed for...". * *Draft 2:* Designed for high-precision audio crossover and filter circuits. This LU44/033/100 | 0,33 mH | 0,30 Ω | 3% | 18 AWG | Air Coil ensures consistent performance in electronic applications. It features an outer diameter of 44mm. * *Checking Draft 2:* * Start with benefit/use case? Yes. * Keyword included? Yes. * No hype words? "Consistent" is factual. No "premium", "best", etc. * Last sentence technical detail? Yes (44mm outer diameter). * Length? 208 characters. * UK English? Yes. Designed for high-precision audio crossover and filter circuits. This LU44/033/100 | 0,33 mH | 0,30 Ω | 3% | 18 AWG | Air Coil ensures consistent performance in electronic applications. It features an outer diameter of 44mm. *Wait, check the keyword again:* LU44/033/100 | 0,33 mH | 0,30 Ω | 3% | 18 AWG | Air Coil. *Check data for technical details:* Outer diameter 44, Total height 30, etc. Let's try one more polish to be very "UK e-commerce professional". "Engineered for high-precision audio crossover and filter circuits. This LU44/033/100 | 0,33 mH | 0,30 Ω | 3% | 18 AWG | Air Coil provides stable inductance for demanding electronic builds. The component has a total height of 30mm." Character count: 223. Sentences: 3. First word: "Engineered" (Benefit/Use case). Keyword: Present. Hype words: None. Last sentence: Technical detail (30mm). Let's double check the "hype words" list. "Premium", "perfect", "fantastic", "best". "Engineered" and "stable" are professional and descriptive. Final check on keyword string: "LU44/033/100 | 0,33 mH | 0,30 Ω | 3% | 18 AWG | Air Coil" Exactly as requested. Final Polish: Engineered for high-precision audio crossover and filter circuits. This LU44/033/100 | 0,33 mH | 0,30 Ω | 3% | 18 AWG | Air Coil provides stable inductance for electronic applications. It features an outer diameter of 44mm. Char count: 215. Wait, the prompt says "The first sentence must start with the strongest benefit or use case, not the product name". "Engineered for..." describes the use case. One more check on the keyword: "LU44/033/100 | 0,33 mH | 0,30 Ω | 3% | 18 AWG | Air Coil". Let's go. Text: Engineered for high-precision audio crossover and filter circuits. This LU44/033/100 | 0,33 mH | 0,30 Ω | 3% | 18 AWG | Air Coil provides stable inductance for electronic applications. It features an outer diameter of 44mm. Wait, is "Engineered" a hype word? No. Is "high-precision" a hype word? It's a technical specification/benefit. "Consistent" or "Stable" are fine. Let's ensure it sounds British. "Crossover" is standard. "Inductance" is standard. "Outer diameter" is standard. Final version: Engineered for high-precision audio crossover and filter circuits. This LU44/033/100 | 0,33 mH | 0,30 Ω | 3% | 18 AWG | Air Coil ensures stable performance in electronic applications. It features an outer diameter of 44mm. Characters: 216. Sentences: 3. Start: Benefit/Use case. Keyword: Included. No hype: Checked. Last sentence: Tech detail. No bullets: Checked. UK English: Checked.
5 790 Ft
(4 559 Ft + VAT)
Saját raktár Out of stock
Külső raktár 2. 2 pcs jún. 19.
Külső raktár 1. jún. 26.
Favorite
Fast Delivery 2-5 working days
Secure Payment Barion & SSL protection
14 Days Exchange We take it back without question
Induktivitás
Technical data
Inductance
Wire diameter
Center hole
Outer diameter
Recess diameter
Total height
Inner diameter
Tolerance
Winding width
Resistance
Ez az Intertechnik légmagos tekercs 0,33 mH induktivitással és 1 mm-es rézhuzallal készült, ami alacsony, 0,30 Ω-os egyenáramú ellenállást (DCR) biztosít. A légmagos kivitel – szemben a ferrit- vagy vasmagos tekercsekkel – nem telítődik nagy áramoknál, így torzításmentes marad a teljes frekvenciatartományban. Ez különösen fontos crossover szűrőkben, ahol a vágási frekvencia pontossága és a jel linearitása a legfontosabb.

A ±3%-os tűrés garantálja, hogy a tekercs paraméterei szűk határok között maradnak, így a szűrő számított értékei a gyakorlatban is pontosan megvalósulnak. Az 1 mm-es huzalátmérő és a 0,30 Ω-os DCR ideális egyensúlyt teremt a veszteség és a méret között: elég alacsony az ellenállás a hatékony energiaátvitelhez, de a tekercs nem foglal túl sok helyet a dobozban.

Ajánlott magas- és középfrekvenciás szűrőkben, ahol a légmagos tekercs alacsony vesztesége és lineáris viselkedése hallhatóan tisztább, részletgazdagabb hangzást eredményez. Párosítható más Intertechnik légmagos tekercsekkel vagy kondenzátorokkal, hogy akusztikailag semleges, pontos crossover hálózatot építs.
