Intertechnik Tritec HQ 40 air-core inductor – 3.90 mH | TRI/DR56 | DCR 0.19 Ω | Cu Tritec 7×0.60 mm | ±3.0%

INTERTECHNIK | Air core coils

Intertechnik Tritec HQ 40 air-core inductor – 3.90 mH | TRI/DR56 | DCR 0.19 Ω | Cu Tritec 7×0.60 mm | ±3.0%

Name: Intertechnik légmagos tekercs 3,90 mH | HQ AudioParts
Brand: Intertechnik
SKU: TRI/DR56/3.90
Availability: LimitedAvailability

SKU: TRI/DR56/3.90

3.9 mH 0.19 Ω

Achieve precise crossover filtering with a low-resistance air-core coil that minimises signal loss. This 3.90 mH inductor offers a DC resistance of just 0.19 Ω for high-fidelity audio performance.

37 090 Ft

(29 205 Ft + VAT)

Own warehouse Out of stock

External warehouse 1. Aug 11.

Favorite

Fast Delivery 2-5 working days

Secure Payment Barion & SSL protection

14 Days Exchange We take it back without question

Induktivitás

3.9

0.68 22 / 43 27

0.68 0.82 1 1 1.2 1.2 1.5 1.5 1.8 1.8 2 2.2 2.2 2.7 2.7 3 3 3.3 3.3 3.9 3.9 3.9 4.7 4.7 4.7 5.6 5.6 5.6 6.8 6.8 6.8 8.2 8.2 9 10 10 12 12 15 15 18 22 27

Technical data

Inductance	3.9 mH
DC Resistance (DCR)	0.19 Ω
Wire diameter	0.6 mm
Center hole	4.5 mm
Outer diameter	56 mm

Total height	61 mm
Inner diameter	33 mm
Tolerance	±3%
Huzalátmérő (AWG)	23 AWG
Winding width	51 mm

Tags

Tritec HQ 40 légmagos tekercs

The Intertechnik Tritec HQ 40 air-core inductor is a premium component designed for audiophiles and loudspeaker builders who demand uncompromising sound quality. This 3.90 mH coil delivers precise crossover filtering with minimal signal degradation, making it an ideal choice for high-fidelity audio systems where clarity and accuracy are paramount. Whether you are constructing custom speakers, upgrading existing crossovers, or restoring vintage audio equipment, this inductor ensures that your music retains its natural detail and dynamic range.

Technically, the Tritec HQ 40 features a low DC resistance of just 0.19 Ω, which significantly reduces power loss and heat generation, allowing your amplifier to drive the speakers more efficiently. The air-core design eliminates core saturation and distortion, preserving the integrity of the audio signal across the entire frequency spectrum. Wound with high-quality Cu Tritec wire measuring 7×0.60 mm, this inductor offers excellent conductivity and thermal stability. With an outer diameter of 56 mm, a central hole of 4.5 mm, and a total height of 61 mm, it fits comfortably into most crossover layouts. The tight tolerance of ±3.0% ensures consistent performance, making this inductor a reliable choice for critical audio applications.
