Intertechnik Tritec HQ 40 air-core inductor – 2.70 mH | TRI/DR56 | DCR 0.15 Ω | Cu Tritec 7×0.60 mm | ±3.0%

INTERTECHNIK | Air core coils

Intertechnik Tritec HQ 40 air-core inductor – 2.70 mH | TRI/DR56 | DCR 0.15 Ω | Cu Tritec 7×0.60 mm | ±3.0%

Name: Intertechnik légmagos tekercs 2,70 mH | HQ AudioParts
Brand: Intertechnik
SKU: TRI/DR56/2.70
Availability: LimitedAvailability

SKU: TRI/DR56/2.70

2.7 mH 0.15 Ω

Achieve precise crossover performance with this high-quality air-core inductor, designed for demanding audio applications. The 2.70 mH coil features a low DC resistance of 0.15 Ω for minimal signal loss.

27 290 Ft

(21 488 Ft + VAT)

Own warehouse Out of stock

External warehouse 1. Aug 11.

Favorite

Fast Delivery 2-5 working days

Secure Payment Barion & SSL protection

14 Days Exchange We take it back without question

Induktivitás

2.7

0.68 15 / 43 27

0.68 0.82 1 1 1.2 1.2 1.5 1.5 1.8 1.8 2 2.2 2.2 2.7 2.7 3 3 3.3 3.3 3.9 3.9 3.9 4.7 4.7 4.7 5.6 5.6 5.6 6.8 6.8 6.8 8.2 8.2 9 10 10 12 12 15 15 18 22 27

Technical data

Inductance	2.7 mH
DC Resistance (DCR)	0.15 Ω
Wire diameter	0.6 mm
Center hole	4.5 mm
Outer diameter	56 mm

Total height	61 mm
Inner diameter	33 mm
Tolerance	±3%
Huzalátmérő (AWG)	23 AWG
Winding width	51 mm

Tags

Tritec HQ 40 légmagos tekercs

The Intertechnik Tritec HQ 40 air-core inductor is a premium component engineered for audiophiles and loudspeaker designers who demand uncompromising crossover performance. With an inductance of 2.70 mH and a low DC resistance of just 0.15 Ω, this coil ensures minimal signal loss and exceptional clarity, making it an ideal choice for high-fidelity speaker systems where precision and transparency are paramount.

This inductor excels in passive crossover networks for high-end bookshelf speakers, floor-standing towers, and studio monitors, where accurate frequency division is critical. Its air-core design eliminates core saturation and distortion, delivering linear performance across the entire audio spectrum. Whether you are building custom loudspeakers or upgrading existing designs, the Tritec HQ 40 provides the reliability and sonic purity required for critical listening applications.

Technically, the inductor is wound with high-purity copper Tritec wire (7×0.60 mm), ensuring excellent conductivity and thermal stability. The outer diameter measures 56 mm, with a central hole of 4.5 mm and a core diameter of 33 mm. The total height is 61 mm, and the winding width is 51 mm, offering a compact yet robust form factor. A tight tolerance of ±3.0% guarantees consistent performance, while the 0.15 Ω DCR minimises power loss and preserves signal integrity.

For demanding audio projects, this Intertechnik air-core inductor delivers the precision and quality needed to achieve outstanding sound reproduction.
