Tang Band W4-655F Full-range Woofer

The Tang Band W4-655F Full-range Woofer represents a masterful blend of compact engineering and full-range audio performance, designed to elevate your high-fidelity audio projects. This 8-inch driver (203.2 mm nominal diameter) delivers exceptional clarity across the frequency spectrum, making it an ideal choice for discerning audiophiles and DIY enthusiasts alike.

Perfectly suited for a variety of applications, this woofer excels in compact loudspeaker designs, near-field monitors, and high-quality multimedia systems. Its full-range capability eliminates the need for a separate tweeter in many setups, simplifying crossover design while maintaining coherent sound reproduction. Whether you are building bookshelf speakers, custom soundbars, or portable audio systems, the W4-655F provides a versatile foundation for achieving natural, detailed sound.

Technically, the driver features an 8-ohm impedance and a sensitivity of 89 dB SPL (1m/2.83V), ensuring efficient power usage and dynamic response. With a maximum power handling of 50 watts, it can deliver satisfying volume levels without distortion. The total Q factor (Qts) of 0.33, combined with a mechanical Q (Qms) of 4.35 and an electromagnetic Q (Qes) of 0.35, indicates a well-damped, controlled bass response. A linear excursion (Xmax) of 3 mm and a low voice coil inductance (Le) of 0.43 mH further contribute to accurate transient reproduction and extended high-frequency extension.

In summary, the Tang Band W4-655F offers a compelling combination of compact dimensions (125 mm depth, 89 mm mounting depth) and high-fidelity performance, making it an excellent choice for your next audio project.
