SB Audience NERO-5CCN125D Mid-range Woofer

SB AUDIENCE | Bass mid-bass subwoofer

SB Audience NERO-5CCN125D Mid-range Woofer

Name: SB Audience Audience mélysugárzó | HQ AudioParts
Brand: SB Audience
SKU: NERO-5CCN125D
Price: 62990.00 HUF
Availability: OutOfStock

SKU: NERO-5CCN125D

127 mm 8 Ω

Achieve high-efficiency midrange and subwoofer performance with a sensitivity of 99 dB at 1m/2.83V, ideal for demanding audio systems. This driver features a total Q factor of 0.73 with chamber, ensuring controlled bass response.

62 990 Ft

(49 598 Ft + VAT)

Saját raktár Out of stock

Külső raktár 2. Out of stock

Let me know when it's available!

We'll send you an email as soon as the product is back in stock.

Fast Delivery 2-5 working days

Secure Payment Barion & SSL protection

14 Days Exchange We take it back without question

Technical data

Nominal diameter	127 mm
Impedance	8 Ω
Resonance frequency (Fs)	122 Hz
Sensitivity (SPL at 1 m / 2.83 V)	99 dB
Power tolerance (max)	250 W

Maximum linear deflection (Xmax)	3.2 mm
Total Q (Qts)	Classic B40 Bookshelf Speakers Oak
Electromagnetic Q (Qes)	Q 3060S Active Subwoofer Black
DC resistance (Re)	5.4 Ω
Voice coil inductance (L_e)	0.03 mH
BL product (BL)	10.6 T·m
The surface area of the cone (Sd)	93.3 cm²
Woofer type	DL200 Audio DAC
Voice coil diameter	38.5 mm
Voice coil carrier	Till
Magnetic material	Neodymium
Dimensions (mm)	159 mm
Screw head diameter	142 mm
Diameter of the baffle cutout	Flex HT 8x8 DSP mm
# Mounting holes	4
Diameter of the access opening	4 mm

The SB Audience NERO-5CCN125D is a precision-engineered midrange and subwoofer driver that delivers exceptional performance for high-fidelity audio systems. Designed for audiophiles and professional installers alike, this driver combines robust construction with outstanding efficiency, making it a versatile choice for a wide range of applications.

Ideal for use in high-end home theatre setups, two-way or three-way speaker designs, and compact subwoofer enclosures, the NERO-5CCN125D excels where clarity and dynamic impact are paramount. Its high sensitivity ensures that even modest amplification can produce impressive sound pressure levels, while its controlled low-frequency response adds depth and authority to music and film soundtracks.

Technically, this driver boasts a remarkable sensitivity of 99 dB at 1m/2.83V, ensuring efficient power usage and high output. The total Q factor (Qts) is 0.73 when used with the supplied chamber, or 0.28 without, offering flexibility for sealed or ported enclosure designs. With a maximum linear excursion (Xmax) of 3.2 mm and a low voice coil inductance of 0.03 mH, it delivers clean, distortion-free reproduction across its frequency range. The 127 mm nominal diameter and 5.4 ohm DC resistance further complement its performance, while the four mounting holes and 142 mm screw circle diameter simplify installation.

In summary, the SB Audience NERO-5CCN125D is a high-efficiency, versatile driver that brings precision and power to any demanding audio project.
